Dakota ZX2 Ultrasonic Corrosion Thickness Gauge

Dakota ZX2 Ultrasonic Corrosion Thickness Gauge
Dakota ZX2 Ultrasonic Corrosion Thickness Gauge
Dakota ZX2 Ultrasonic Corrosion Thickness Gauge
Dakota ZX2 Ultrasonic Corrosion Thickness Gauge
Dakota ZX2 Ultrasonic Corrosion Thickness GaugeDakota ZX2 Ultrasonic Corrosion Thickness GaugeDakota ZX2 Ultrasonic Corrosion Thickness GaugeDakota ZX2 Ultrasonic Corrosion Thickness Gauge
Manufacturer Dakota Ultrasonic
Application
Country of Manufacture US
Features
  • 2 programmable and 8 pre-set material velocities:
    (aluminium, cast iron, plexiglass, polystyrene, polyurethane, PVC, stainless steel and steel)
  • Measurement range of 0.63 to 914.4mm / 0.025 to 36.00"
  • Velocity range of 305 to 18,542m/sec / 0.0120 to 0.7300in/µs
  • Frequency range of 1 to 10MHz
  • Resolution of 0.01mm / 0.001"
  • Pulse-echo measurement mode
  • Automatic V-path error compensation
  • Built-in probe zero disc
  • Metric or imperial units
  • Bar graph indicates reading stability
  • Hardwearing, gasket sealed, aluminium casing
  • Operating range of -30 to +75°C
  • Large LCD screen with selectable brightness
  • Portable and lightweight (weighs only 312g)
Includes
  • 1/4", 5MHz dual-element transducer:
    (multi-purpose - suited to steels, glass and thin plastics)
  • Couplant
  • Batteries (2 x AA)
  • Hard plastic carry case
  • NIST traceable calibration certificate
  • Manual
Manuf. Model
Z-301-0003
Measurement Type
Returns Policy
Covered by our 7 day NQA return guarantee. See our help section for full details.
Warranty
5 Years

Dakota ZX2 Ultrasonic Corrosion Thickness Gauge

Manufacturer Dakota Ultrasonic
Application
Country of Manufacture U.S.
Features
  • 2 programmable and 8 pre-set material velocities:
    (aluminium, cast iron, plexiglass, polystyrene, polyurethane, PVC, stainless steel and steel)
  • Measurement range of 0.63 to 914.4mm / 0.025 to 36.00"
  • Velocity range of 305 to 18,542m/sec / 0.0120 to 0.7300in/µs
  • Frequency range of 1 to 10MHz
  • Resolution of 0.01mm / 0.001"
  • Pulse-echo measurement mode
  • Automatic V-path error compensation
  • Built-in probe zero disc
  • Metric or imperial units
  • Bar graph indicates reading stability
  • Hardwearing, gasket sealed, aluminium casing
  • Operating range of -30 to +75°C
  • Large LCD screen with selectable brightness
  • Portable and lightweight (weighs only 312g)
Includes
  • 1/4", 5MHz dual-element transducer:
    (multi-purpose - suited to steels, glass and thin plastics)
  • Couplant
  • Batteries (2 x AA)
  • Hard plastic carry case
  • NIST traceable calibration certificate
  • Manual
Manuf. Model
Z-301-0003
Measurement Type
Returns Policy
Covered by our 7 day NQA return guarantee. See our help section for full details.
Warranty
5 Years
Loading..


0 in Stock (Available for Order)
Allow 2-4 weeks for backorders.
Register/Login

The Dakota ZX2 is an economical and easy to use ultrasonic thickness gauge.

Calibration can either be set to one of eight common material types stored on the gauge (aluminium, cast iron, plexiglass, polystyrene, polyurethane, PVC, stainless steel and steel) or by entering a known material velocity.

Fast, accurate measurements to 0.01mm give you reliable test results and save time and money in the field. A rugged, water resistant, sealed aluminium casing means the ZX2 is built to withstand everyday use in heavy duty, industrial workplaces.

The ZX2 is ready to operate straight out of the box and is backed by Dakota's legendary 5 years limited warranty.
