The ProComSol HM-USB-ISO HART modem streamlines and simplifies smart instrumentation communications, freeing technicians, engineers (and budgets) from heavy and expensive, single-function, field device communicators.

The HM-USB-ISO provides a fast and reliable connection between HART transmitters and HART communications software.

Linking HART software on any USB-enabled Android or Windows host device to HART-compliant process instrumentation, the HM-USB-ISO modem enables reliable data access, device configuration, monitoring, troubleshooting and calibration.

Integrated heavy-duty minigrabber test clips and a 1.2m / 4ft cable let you easily connect with smart field instruments using existing familiar hardware.

Features and Specifications:

• Works with HART software including ProComSol DevCom2000 (Windows) and DevComDroid (Android)
• Self powered - no external power supply or batteries
• Boost feature for low resistance loops (requires DevCom2000 software)
• Rugged ABS plastic housing
• Protective rubber boot
• USB type A connector
• Mini-grabber clip connectors
• 0.5m / 18" USB type A cable
• 1.2m / 4ft HART cable
• Meets FieldComm Group specification HCF_SPEC-54
• 1,500V DC electrical isolation between HART and USB circuits
• Protects hardware from filed loop noise and surge
• Easy to install Windows virtual serial / COM port
• Supports 32 and 64-bit Windows OS
• Operating temperature range of 0 to +50°C
• Compact (70 x 51 x 20mm)
• Lightweight (122g)
• 1 year warranty
