PIE 334 mA Loop Calibrator

PIE 334 mA Loop Calibrator
PIE 334 mA Loop Calibrator
PIE 334 mA Loop Calibrator
PIE 334 mA Loop CalibratorPIE 334 mA Loop Calibrator
Manufacturer Practical Instrument Electronics (PIE)
Features
  • Sources from 0.00 to 24.00 mA / -25.0 to 125.0%
  • Reads from 0.00 to 52.00 mA / -25.0 to 300.0%
  • Reads from -99.99 to +99.99V DC
  • Accuracy of up to 0.03%
  • Resolution of 0.01 mA / 10 mV
  • Simulates in loops powered from 3 to 100V DC
  • Powers and measures 2-wire transmitters to 27V DC
  • Drives up to 1200Ω loads
  • Instantly outputs at three points from 0.00 to 24.00 mA
  • Speed sensitive digital potentiometer
  • Fuseless over-voltage protection to 135V AC / DC
  • Overload current protection to 25 mA
  • Operating temperature range of -20 to +60°C
  • Small and lightweight (weighs only 220g)
Includes
  • Batteries (4 x AA)
  • Test leads (attached)
  • NIST traceable calibration certificate
  • Manual
Manufacturer Model
334
Warranty
3 Years

PIE 334 mA Loop Calibrator

Manufacturer Practical Instrument Electronics (PIE)
Features
  • Sources from 0.00 to 24.00 mA / -25.0 to 125.0%
  • Reads from 0.00 to 52.00 mA / -25.0 to 300.0%
  • Reads from -99.99 to +99.99V DC
  • Accuracy of up to 0.03%
  • Resolution of 0.01 mA / 10 mV
  • Simulates in loops powered from 3 to 100V DC
  • Powers and measures 2-wire transmitters to 27V DC
  • Drives up to 1200Ω loads
  • Instantly outputs at three points from 0.00 to 24.00 mA
  • Speed sensitive digital potentiometer
  • Fuseless over-voltage protection to 135V AC / DC
  • Overload current protection to 25 mA
  • Operating temperature range of -20 to +60°C
  • Small and lightweight (weighs only 220g)
Includes
  • Batteries (4 x AA)
  • Test leads (attached)
  • NIST traceable calibration certificate
  • Manual
Manufacturer Model
334
Warranty
3 Years
Loading..

Trade Customers

Login for your specific pricing.

Queries or Big Orders?

[email protected]


0 in Stock (Available for Order)
Allow 2-4 weeks for backorders.
Configure this item to show pricing…
Register/Login

The PIE 334 4-20 mA loop calibrator provides greater stability, accuracy, reliability and battery life than competitor's models.

  • Calibrate Milliamp Instruments:
    Source 0.00 to 24.00 mA
    Source -25.0 to 125.0% of 4-20 mA
    Read 0.00 to 52.00 mA
    Read -99.99 to 99.99 V
    Simulate 2-wire transmitters
    Power and read 2-wire transmitters

  • Calibrate with Confidence:
    Accurate to ±0.025% of span
    EZ-CHECK outputs
    3 year manufacturer's warranty

  • Use in the Plant, Field or Shop:
    Compact. lightweight and easy to carry
    Includes rubber boot and attached test leads
    Low profile switches resist accidental damage
    Backlit display with large digits for use in dark areas

  • Simple Battery Changes:
    Separate compartment for no-tool battery changes
    Calibration seals remain intact
    Powered by 4 x AA batteries (included)
