Crystal XP3i 700 Bar Digital Test Gauge

Crystal XP3i 700 Bar Digital Test Gauge
Crystal XP3i 700 Bar Digital Test Gauge
Crystal XP3i 700 Bar Digital Test Gauge
Crystal XP3i 700 Bar Digital Test GaugeCrystal XP3i 700 Bar Digital Test GaugeCrystal XP3i 700 Bar Digital Test Gauge
Manufacturer Crystal Engineering
Application
Country of Manufacture US
Ex Cert
Ex Zone
Features
  • Bluetooth low energy and USB-C connectivity
  • Crystal Connect mobile app for wireless communication
  • Crystal Control Web cloud software for remote access, configuration, data sharing and collaboration
  • 200 million logging points with DataLoggerXP upgrade
  • PSV test mode captures open and reseat values
  • Ultra-low power mode for over 1 year of continuous use
  • IP67 rated, dust and submersion-proof housing
  • Marine grade, corrosion resistant, nickel-plated aluminium casing
  • Active digital temperature compensation from -20 to +50°C
  • 7/16"-20 MP (Crystal CPF) female connection
  • Interchangeable CPF adapter
  • Configurable for torque, force, level or any user defined units
  • Large, backlit, high contrast LCD screen
Includes
  • Adapter
  • Batteries (3 x AA)
  • Hanging strap
  • Crystal Connect mobile app (free download)
  • Crystal Connect Web configuration software (free download)
  • ISO17025 (NATA equivalent) calibration certificate
  • Manual
Manuf. Model
XP3i-700BAR
Returns Policy
Covered by our 7 day NQA return guarantee. See our help section for full details.
Warranty
12 Months

Second Line Shows Tare, Leak Rate, Peak, Average or Logging Memory Points (if Data Logger Enabled)
Crystal XP3i Gauge Dual Line Display
Crystal XP3i Gauge Dual Line Display

Full Scale Uncertainties Meet DNV Hydrostatic Testing Requirements

Rated to 700 Bar, Stainless Steel
Gauge Adapter

7/16"-20 MP (Crystal CPF) Female Connection
Pressure Port Configuration

200 Million Data Points
Bluetooth and App-Based Remote Control
Adjustable Sample Rates from 0.2 Seconds to 24 Hours
Includes - Gauge Firmware Upgrade, USB Cable and Instructions
Crystal XP3i Gauge DataLoggerXP
Crystal XP3i Gauge DataLoggerXP

Crystal XP3i 700 Bar Digital Test Gauge

Manufacturer Crystal Engineering
Application
Country of Manufacture U.S.
Ex Cert
Ex Zone
Features
  • Bluetooth low energy and USB-C connectivity
  • Crystal Connect mobile app for wireless communication
  • Crystal Control Web cloud software for remote access, configuration, data sharing and collaboration
  • 200 million logging points with DataLoggerXP upgrade
  • PSV test mode captures open and reseat values
  • Ultra-low power mode for over 1 year of continuous use
  • IP67 rated, dust and submersion-proof housing
  • Marine grade, corrosion resistant, nickel-plated aluminium casing
  • Active digital temperature compensation from -20 to +50°C
  • 7/16"-20 MP (Crystal CPF) female connection
  • Interchangeable CPF adapter
  • Configurable for torque, force, level or any user defined units
  • Large, backlit, high contrast LCD screen
Includes
  • Adapter
  • Batteries (3 x AA)
  • Hanging strap
  • Crystal Connect mobile app (free download)
  • Crystal Connect Web configuration software (free download)
  • ISO17025 (NATA equivalent) calibration certificate
  • Manual
Manuf. Model
XP3i-700BAR
Returns Policy
Covered by our 7 day NQA return guarantee. See our help section for full details.
Warranty
12 Months
Loading..

SKU: XP3i-700BAR
Configure this item to show pricing…
Register/Login
Discounts are available for larger orders and resellers. Please login to review your specific pricing or contact us to open a trade account.

IECEx Ex ia IIC T3...T4 Ga
(FTZU23.0017X)

The world's most popular test gauge is now even better!
IECEx and ATEX certified for zone 0 hazardous areas with up to 0.02% accuracy.

It's still not like other pressure gauges...

The Crystal XP3i gauge takes everything you love about the legendary XP2i model and adds a range of game-changing new features:

Standard accuracy of 0.05% of reading -
Twice as accurate as the standard XP2i gauge.

Bluetooth low energy and Crystal Connect mobile app -
Connect wirelesssly and safely in hazardous areas, view live data and download recorded tests.

Crystal Control Web cloud software -
Access, manage and configure your XP3i gauge from anywhere. Share logging data immediately and collaborate with colleagues worldwide.

Massive 200 million point data logging memory -
Over 6,000 times more storage space than the XP2i gauge.

Highly flexible and configurable, the XP3i is available with a choice of accuracies; an optional rear pressure port and flange adapters for panel mounting; or a dual-line display to show live pressure plus tare, peaks, average, leak rate or differential pressure when connected to a second gauge.

Every XP3i comes with an ISO17025 accredited (NATA equivalent) calibration report, showing data over the full temperature compensated range of -20 to +50°C.
