The Ametek Jofra CTC-652 dry block compact temperature calibrator is a high precision reference temperature source.

Purpose-built for field and workshop use, the CTC-652 provides the portability, efficiency and accuracy essential for time-critical industrial temperature testing and calibration.

Key Features & Specifications

Wide Temperature Range:
Operates between 28 and 650°C

Fast Heating, Cooling and Stabilisation Times:
Heats from ambient (23°C) to 650°C in 33 minutes
Cools from 650 to 100°C in 48 minutes
Cools from 100 to 50°C in 25 minutes
Reaches stability in 5 minutes

Exceptional Accuracy, Stability and Resolution:
Accurate to 0.35°C with external reference sensor
Accurate to 0.50°C with internal reference sensor
Stability of 0.05°C
Adjustable resolution of 1 / 0.1 / 0.01°C / °F / K

Deep Immersion Depth with Temperature Uniformity;
A tall 390mm body provides an extended well depth of 190mm / 7.5" to calibrate longer or liquid-filled sensors
Non-linear heating elements monitor axial and radial uniformity within the well, ensuring a homogeneous temperature for reliable calibrations

Mains Variance Immunity Circuitry:
Mains Variance Immunity (MVI) circuitry maintains stability and accuracy during power fluctuations caused by large electrical motors or heavy industrial equipment
MVI circuitry continuously monitors the CTC-652's supply voltage, making adjustments to ensure a consistent energy flow to the heating elements

Time-Saving Features:
Built-in auto-stepping and switch test functions automate routine procedures, saving time and streamlining operations

Fully Configurable for Your Application:
CTC-652 models provide a choice of basic or advanced functionality, with an optional external sensor input and custom-built smart reference sensor for increased accuracy
A wide well diameter and a broad range of interchangeable single or multi-hole inserts suit almost any metric or imperial-sized sensor under test
A support rod kit protect cables and provides stable mounting for delicate, long or heavy sensors while ensuring a fixed immersion depth
A custom-built carry case provides increased portection, security and accesssories storage

Lightweight, Portable and Versatile:
Weighing only 9kg, the CTC-652 is easy to transport and position
A wide operating temperature range of 0 to 50°C allows operation in harsh conditions
Silent operation mode allows use in noise-sensitive environments

Delivered Ready for Immediate Operation:
Every Jofra CTC-652 is delivered as standard with:
Heat shield
Test leads
JofraCal calibration software
USB cable
Insert removal tool
Mains power cable
Calibration certification
Manuals

Why Choose Transtek for Your Test and Calibration Needs?
At Transtek, we provide top-tier testing and calibration equipment from the world's most trusted brands to meet demanding requirements and ensure reliability and accuracy in the field.
Dedicated to providing expert service and support beyond the inital purchase, we can also organise recalibration of the CTC-652 and any external reference sensors to Australian NATA standards once the included manufacturer's calibration certificates expire.
Find out more about our comprehensive NATA calibration services here.
